Siemens 7MF4233 series

UMSITRAPDS3-1 Model Designations and Specifications
November 2005
9-9
Other versions
Add "-Z" to order number and add short spec.
7MF4433 - . . . . . - . . . . – Z
Transmitter with mounting bracket of:
- steel
A01
- stainless steel
A02
Process flange O-ring (instead of FPM (Viton)) of:
- PTFE (Teflon)
A20
- FEP (with silicone core, foodstuff compatible)
A21
- FFPM (Kalrez)
A22
- NBR (buna N)
A23
Han 7D plug
6)
A30
Han 8U plug (instead of Han 7D)
6)
A31
Sealing screws (1/4-18 NPT) with valve in same material as process flanges
A40
Labeling of rating plate (instead of German):
- English
B11
- French
B12
- Spanish
B13
- Italian
B14
Manufacturer test certificate M acc. To DIN 55350, Part 18, and acc. to ISO 8402
C11
Acceptance test certificate B acc. to DIN 50 049 / EN 10 204-3.1 B
C12
Works certificate acc. To DIN 50 049-2.2 / EN 10 204-2.2
C14
Setting the upper output current limit to 22.0 mA
D05
Acid gas version acc. To NACE only with Hastelloy process diaphragm and
stainless steel process flange screws
D07
IP 68 (not with Han 7D/Han 8U plug and cable screwed gland Pg 13.5)
D12
Application in zone 0 (basic device EEx ia)
6)
E02
Overfill protection for combustible and non-combustible liquids
(PN 470 psi maximum) (basic device EEx ia)
E08
Oxygen application (for oxygen measurement and inert liquid: 2325 psi maximum)
E10
Switching the process connection side (HP side: left, LP side: right)
H01
Lateral vent for gas measurement
H02
Stainless steel process flanges for vertical active pressure lines (not with supplements K01 or
K02)
H03
Process flanges:
- without process flanges
K00
- Hastelloy flanges
K01
- Monel flanges
K02
Measuring range to be set, specify in clear text,
For linear characteristic: ... to ... mbar, psi, kPa, MPa, ... (27 characters maximum)
Y
01
For square root characteristic: 0 to ... mbar, psi, kPa, MPa, ... (27 characters maximum)
Y
02
Tag number / description (16 characters maximum) specify in clear text:
Y
15
Tag message (27 characters maximum) specify in clear text:
Y
16
Setting digital display specify in clear text: mbar, psi, kPa, MPa, …
Y
20
Factory presettings other than "Y01" or "Y02", "Y20" and "D05" are not possible.
Notes:
1)
Not suitable for remote process mounting
5)
Not for “explosion proof” degree of protection
2)
Only with span D, F, G, or H
6)
Not FM approved
3)
For stainless steel process flange screws
7)
Not with K01 or K02
4)
Without cable screwed gland Ordering example:
Scope of delivery: Position line: 7MF9933-1DA00-1AA1-Z
Transmitter as ordered, 1 brief instruction (Leporello) B-line: A01+B11+C14+Y01+Y15
2 sealing screws (same material as process flange) C-line: Y01: 50…150 inH
2
O
C-line: Y15: PIC 1758
