Siemens 7MF4233 series

UMSITRAPDS3-1 Model Designations and Specifications
November 2005
9-11
Other versions
- PTFE (Teflon)
A20
- FEP (with silicone core, foodstuff compatible)
A21
- FFPM (Kalrez)
A22
- NBR (buna N)
A23
Han 7D plug (metal, gray)
4)
A30
Han 8U plug (instead of Han 7D)
4)
A31
Sealing screw (1/4-18 NPT) with valve in the same material as
the process flanges
A40
Labeling of the rating plate (instead of German):
- English
B11
- French
B12
- Spanish
B13
- Italian
B14
Manufacturer test certificate M according to DIN 55350, Part 18,
and according to ISO 8402
C11
Acceptance test certificate B according to DIN 50 049 / EN 10 204-3.1 B
C12
Works certificate according to DIN 50 049-2.2 / EN 10 204-2.2
C14
Setting the upper output signal limit to 22.0 mA
D05
Acid gas version according to NACE, only with Hastelloy process
diaphragm and stainless steel process flanges, PN 4569 psi maximum
D07
Stainless steel process flange screws, PN 6090 psi, basic device with
machined stainless steel process flange screws
D09
IP 68 (not with Han 7D/Han 8U plug and cable screwed gland Pg 13.5)
D12
Application in zone 0 (basic device EEx ia)
4)
E02
Switching the process connection side
H01
Lateral vent for gas measurement
H02
Stainless steel process flanges for vertical active pressure lines
H03
Measuring range to be set, specify in clear text,
For linear characteristic: ... to ... mbar, psi, kPa, MPa, ... (27 characters
maximum)
Y
01
For square root characteristic: 0 to ... mbar, psi, kPa, MPa, ..(27 characters
maximum)
Y
02
Tag number / description (16 characters maximum) specify in clear text:
Y
15
Tag message (27 characters maximum) specify in clear text:
Y
16
Setting digital display, specify in clear text: mbar, psi, kPa, MPa, ...
Y
20
Factory pre-settings other than "Y01" or "Y02", "Y20" or "D05" are not possible.
Notes:
1)
Only with span D, F, G, or H; maximum PN 4569 psi and only with stainless steel process flange screws
2)
Without cable screwed gland
3)
Not with "explosion proof" degree of protection
4)
Not FM approved
Scope of delivery
: Transmitter as ordered, 1 brief instruction (Leporello)
2 sealing screws (same material as process flanges)
Ordering example:
Position line: 7MF4533-1DA10-1AA1-Z
B-line: Y01
C-line: Y01: 36.1… 57.4 inH
2
O
