Technical specifications - CIM
Article numbers
CIM
6ED1055-5MC08-0BA2
Attachment to Industrial Ethernet
Interface X1P1-P4 for local applications
Quantity
4
Design
RJ-45 jack
Properties
10/100-Base-T, autocrossover, autonegotiation
Transmission speed
10 / 100 Mbps
Permitted cable lengths (Ethernet)
(Alternative combinations per length range) *
0 ... 100 m
• Max. 100 m Standard Category 5 shielded twisted-pair
Ethernet cable with shielded RJ45 connector.
Electrical data
Power supply
• Power supply
• Range
• Design
• 12/24 V DC nominal
• 10.2 to 28.8 V DC
• 3-pin terminal strip, not floating
Current consumption
• At 12 V
• At 24 V
• Maximum 1 A (including 4G and supercapacitor charging)
• Maximum 500 mA (including 4G and supercapacitor charg-
ing)
Effective power loss
Maximum 10.5 W
Permitted ambient conditions
Ambient temperature
• During operation
• During storage
• -20 °C to +55 °C
• -40 °C to +70 °C
Relative humidity at 25 °C
Maximum 95 %, non-condensing
Altitude during operation
up to 3000 m
Electromagnetic compatibility (EMC)
Criterion
Tested in accord-
ance with
Values
Radiated emission EN 55011
EN 55022
Limit class B group 1
Limit class B
Electrostatic discharge IEC 61000-4-2 ±2 kV, ±4kV, ±8 kV air discharge
±6 kV contact discharge
