Application and functions
1.5 SGLAN
CIM
14 Operating Manual, 11/2022, A5E51250518-AC
Item Type Size Ad-
dress
Range Unit comments Sample for Restful
Interface
short
unsigned
1 byte
942
0 ~ 9
0.1 m
altitude (fractional part)
/pi/rest/vsu942
real 4 bytes 943 -9999.9 ~
9999.9
m altitude in float format /pi/rest/vr943
speed
1
unsigned
2 bytes
933
0 ~ 9999
km/h
speed (integer part)
/pi/rest/vu933
short
unsigned
1 byte
935
0 ~ 9
0.1 km/h
speed (fractional part)
/pi/rest/vu935
real
4 bytes
936
0 ~ 9999.9
km/h
speed in float format
/pi/rest/vu936
1
available for CIM V1.1 and later versions.
1.5 SGLAN
SGLAN (secured global local area network) allows you to create a private network with CIM.
SGLAN is the fundamental building block for your private network. Devices in the SGLAN can
communicate with each other securely.
