Web-based configuration
5.4 Web pages
CIM
Operating Manual, 11/2022, A5E51250518-AC
65
9. Save your changes.
10.Click ⑨ to close the Data transfer table.
Note
You can add maximum of 16 rows most.
Data transfer restrictions
The table below describes the range and local address restrictions for client connections.
Read and Write requests:
Local address (CIM) Remote address (S7 compatible
device)
Address Type
Range
Address Type
IB
0 to 511
IB, QB, MB, VB, Data Block
QB
0 to 511
MB
0 to 511
VB
0 to 1023
IW
0 to 510
IW, QW, MW, VW, Data Block
QW
0 to 510
MW
0 to 510
VW
0 to 1022
ID
0 to 508
ID, QD, MD, VD, Data Block
QD
0 to 508
MD
0 to 508
VD
0 to 1020
Note
The address type is the combination of the process image name in
UDM (Page 11) and data
type. For example, IB means byte in memory I.
The values should
follow the rule: Local address + Data length ≤ Max value of Local address
type.
