Web-based configuration
5.4 Web pages
CIM
74 Operating Manual, 11/2022, A5E51250518-AC
Sample
The [address type][type][range] portion with in the examples below can be exchange with
any of the allowed parameters.
Example
Description
https://xxx.xxx.xxx.xxx:xxx/pi/rest/
ix5.3~8.7
All bits at [5.3, 8.7] in range I
https://xxx.xxx.xxx.xxx:xxx/pi/rest/
i
https://xxx.xxx.xxx.xxx:xxx/pi/rest/
ix
All bit in range I
https://xxx.xxx.xxx.xxx:xxx/pi/rest/
ix5.3
A bit at 5.3 in range I
https://xxx.xxx.xxx.xxx:xxx/pi/rest/
ix5.3~8.7
All bits in [5.3, 8.7] in range I
https://xxx.xxx.xxx.xxx:xxx/pi/rest/
iw100
A word at 100 in range I
https://xxx.xxx.xxx.xxx:xxx/pi/rest/
iw100~200
All words in [100, 200] in range I
https://xxx.xxx.xxx.xxx:xxx/pi/rest/
iw100~
All words in [100, range_end] in range I
https://xxx.xxx.xxx.xxx:xxx/pi/rest/
qb100
A byte at 100 in range Q
https://xxx.xxx.xxx.xxx:xxx/pi/rest/
qr100
A real at 100 in range Q
https://xxx.xxx.xxx.xxx:xxx/pi/rest/
qr~100
A real at [range start, 100] in range Q
https://xxx.xxx.xxx.xxx:xxx/pi/rest/
qr-100~-200
All reals at [(range_size-200), (range_size-100)] in
range Q
https://xxx.xxx.xxx.xxx:xxxx/pi/rest
/ix0.0&qi12
A bit at 0.0 in range I and a bit at 12 in range Q
1
1
Starting from
/pi/rest/
, the length of the command should be within 500 English Characters.
Note: an wrong connector will cause the addresses cannot be recognized.
