System description
11
Building Technologies A6V10265083_a_en_--
Fire Safety & Security Products 03.2010
3.5 Technical data
Collective lines (zones) 8 or 12
Number of detectors per line max. 32
Compatible detector series Detector line type “Cerberus”
– Cerberus (DS1100, MS24, MS9, MS7, MS6)
– Sinteso (FDOOT249-1) 4)
Detector line type Standard
– Standard (Synova Series 300C)
Ratings detector line
Operating voltage / quiescent current
Line resistance / capacitance
– Type Cerberus
– Type Standard
Alarm criteria
– Type Cerberus
– Type Standard
Alarm-Trigger
– Type Cerberus
– Type Standard
Line termination
– FC10xx-A/ -C
– FC10xx-B
18 … 22 V / max. 3.2 mA
≤ 80 Ω or ≤ 50 Ω / ≤ 1 μF 1)
≤ 100 Ω or ≤ 50 Ω / ≤ 1 μF 1)
17.5 ... 39 mA and > 5.1 V
17 ... 83.6 mA
resistor 820 Ω or Z-diode 5.6 V 2)
resistor 820 Ω or Z-diode 5.6 V 3)
resistor 3.9 kΩ
EOL FCE1003-B
Monitored control lines
Voltage/current in state active
Line termination
2 + 4 optional
24 V max. 500 mA per line (peak max. 2 A)
EOL FCE1002
Potential-free contacts 1 x Alarm, 1 x Fault / max. 1 A/30 V
Control inputs 6 x 24 V switched via contact
Fire control outputs 6 + 1 per zone / max. 40 mA/24 V
Fire control relays max. 6 (optional) / max. 10 A/230 VAC
Power supply
Mains voltage
Power consumption
maximum nominal output current without
battery charging, I max. b
Minimum ouput current I min
System supply voltage
mains failure delay
85 … 265 VAC
max. 90 VA
2.5 A
0.05A
21 … 28.6 VDC
10 min.
Supply output (Battery
Operation time
Battery size
Voltag
Load resistance Rimax
Emergency power
maximum nominal output current during
battery charging, I max. a
Quiescent current
– 8 zones
– 12 zones:
– with additional control line extension card
– with additional display module
Alarm current per zone
Battery low discharge cut off
Charging temperature compensated
max. 30 h (12 Ah) or max. 72 h (17 Ah) 5)
2 x 12 V/12 Ah or 2 x 12 V/17 Ah, lead acid
21….28.6 VDC
Max. 1 Ohm (battery incl. line)
0.9A
145 mA
165 mA
84 mA
7.5 mA
+ 35 mA (without current of external alarm devices)
< 20.5 VDC
Yes
Cabinet
Assembly
Color
Protection degree
Dimension (W x H x D)
metal frame with plastic cover
metal frame grey RAL9006 / cover white RAL9003
IP40
506 x 378 x 125 mm
Temperature range (operation) 0 … 50 °C
1) Line resistance ≤ 50 Ω if option 4 is selected in step 3 and option 8 is selected in step 15.
2) Use 5.6 V z-diode if option 4 is selected in step 3 and option 8 is selected in step 15.
3) Use 5.6 V z-diode if option 4 is selected in step 3 and option 8 is selected in step 15. In all other
cases, use 820 Ω resistor or standard call point with integrated alarm detection.
4) For details, see list of compatibility (008331)
5) The battery capacity calculation depends on the connected hardware devices, country and/or
customer required emergency lifetime.
