Siemens FC1008-A User Manual

Commissioning
28
Building Technologies A6V10265083_a_en_--
Fire Safety & Security Products 03.2010
7 Commissioning
7.1 Procedure
Work to be done before commissioning
 installation of detector lines must be completed
 the connection of all detector bases and manual call points must be tested
 control unit must be mounted
 inscription stripes must be labeled and inserted
 all accessories must be available on site
 mains supply voltage must be available
 list of all field devices with clear geographical location must be available
Check electronic hardware
 check position of all jumpers and DIP switches
 connect detection lines or terminate with EOL
 connect control lines or terminate with EOL
 check whether the EOL is connected at the last detector, manual call point or
horn of each line
 remove mains fuse inside the control unit
DANGER External voltage
 connect mains supply line according to the local mains voltage
– check mains fuse and earth connection
 place battery (but do not connect)
 insert mains fuse inside the control unit
 connect battery
Commissioning
 check the correct functioning of the system
 remove possible faults
 set the individual user functions as required and fill out log sheet
 initiate lamp test and check all LED
 test each operating key for correct functioning
 test all detectors, manual call points, horn control lines and remote transmission
facility, see chapter Testing peripheral devices
The commis
sioning work is completed if
 the alarm processing of each zone is individually tested
 all detectors, manual call points, horn control lines and remote transmission fa-
cility have been tested and function correct
 the log sheet of user functions is completely filled out
 the system is set to normal operation and all system parts are enabled
 no fault message is reported
 the buzzer is enabled (jumper on mainboard)
 temporary operating access is removed (jumper on mainboard)
 fill in the external product sticker with the correct information and stick it on cover
The system can now be handed over the customer
