Siemens FC1008-A User Manual

Configuration
37
Building Technologies A6V10265083_a_en_--
Fire Safety & Security Products 03.2010
8.3.11 Step 11, cross zoning
LED zone 1 - x Option Setting Key
Red yellow
Function: Zone pair in cross-zoning on alarm
1 no cross-zoning Default off
2 cross-zoning type 1
– zone A or B = no Alarm *
– zone A + B = Alarm 1
on
3 cross-zoning type 2
– zone A or B = Alarm 1
– zone A + B = Alarm 2
zone A+B
on
4 cross-zoning type 3
– zone A or B = Alarm 0 (internal alarm)
– zone A + B = Alarm 1
– on on
Remark: Only possible with defined zone pairs 1+2, 3+4 up to 11+12. Named in table with A and B.
Procedure:
1. Hold zone key A then press zone key B
– Type 1 is now selected (red LED on both zones are lit)
2. Hold zone key A then press zone key B
– Type 2 is now selected (yellow LED on both zones are lit)
3. Hold zone key A then press zone key B
– Type 3 is now selected (red and yellow LEDs on both zones are lit)
4. Hold zone key A then press zone key B
– No cross zoning selected (no zone LED lit)
* No Alarm: Only zone LED and buzzer are activated.
8.3.12 Step 12, access code
LED zone 1 LED zone 2 Option Setting Key
Red Yellow Red yellow
Function: Password to provide operating access (level 2)
1 basic access code (4, 2, 3, 3) defined Default off
2 individual access code
Procedure:
1. enter code by pressing key 1 to 4 in
the desired sequence then press key
zone 1
– red LED flashing
2. repeat same input sequence and
press key zone 1 again (confirm code)
– red LED now turns to on
– yellow LED on = code not accepted
(repeat procedure)
zone 1
on
3 no access code required
(access via key switch)
zone
1 + 2
on on
Note: Access is permanently provided if jumper PU16 is set on mainboard (override of access
code)
8.3.13 Step 13, special PMI parameters
LED zone 1 LED zone 2 Option Setting Key
Red Yellow Red yellow
Function: Reminder beep (Buzzer) upon Fault and System part Disabled
1 no reminder beep Default off
2 reminder beep activated
– beep of 1 sec. every 4 min.
zone 1
on
Function: Fault messages to be Reset
3 Acknowledged faults must not be reset Default off
4 Faults must be acknowledged and after
being restored reset
zone 2
on
