Operation and indicator elements, mode of operation (PMI)
27
Building Technologies A6V10265083_a_en_--
Fire Safety & Security Products 03.2010
6.2.4 Poll service informations
The following information can be displayed on the display module:
last change of configuration (date/time and check sum)
last test alarm (date/time and zone number)
version of firmware
Requirement
Queries about service information are only possible if there is no alarm and operat-
ing access on level 2 is given.
Procedure
1. Hold key acknowledge then, enter the password for the corresponding service
information by using the numeric keys.
2. The requested query can be selected with the corresponding numeric keys.
3. To end the query, press key acknowledge. The request will be automatically
stopped if an alarm occurs or if there is no further entry for more than a minute.
Query about the last change of configuration
Entry Meaning Display (example)
Hold key acknowledge and
enter 11114444
password P R O G
1 year (yyyy) 2 0 0 3
2 date (dd.mm.) 2 1.0 5.
3 time (hh.mm) 1 5.3 7
4 check sum user function 8.2.3.6.
Query about the last test alarm
Entry Meaning Display (example)
Hold key acknowledge and
enter 33331111
password T E S T
1 year (yyyy) 2 0 0 3
2 date (dd.mm.) 2 1.0 5.
3 time (hh.mm) 1 5.3 7
4 zone 0 8
Request about the firmware
Entry Meaning Display (example)
Hold key acknowledge and
enter 2211
password entry
firmware version is displayed
V._.6.1
6.2.5 Delete alarm counter and event memory
Common command to delete both alarm counter and event memory.
1. Start hold key acknowledge and key in code 3, 3, 2, 2, 1, 4, 4, 3
by using numeric keys
D E L static
2. Approve hold key reset and key in code 3, 4, 4, 1, 3, 3, 2, 1 by using
numeric keys
. D E L . flash simultaneously
3. Delete press numeric key 2 . D E L . static
4. Confirm press simultaneously all numeric keys 0 0 0 0 flash for 15 sec.
5. End press key acknowledge possible at any time
Automatic stop when alarm or 15 sec. after last entry
