8.3 Programmable functions
1234
4
3
2
1
7
32
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1 4 5 6
9 9 9 9
8
9 9 9 9
8
Procedure
1. Select the desired step with key (2) or (3)
2. Press the zone keys (6) as many times until the desired option is indicated with
the corresponding zone LED (5) according to the following tables.
8.3.1 Step 1, timer V1
LED zone 1 LED zone 2 Option Setting Key
red yellow red yellow
Function: Timer V1 on alarm or fault in mode manned
1 0.5 min. Default off
2 1 min. on
3 2 min.
zone 1
on
4 3 min. on
5 4 min.
zone 2
on
8.3.2 Step 2, timer V2
LED zone 1 LED zone 2 Option Setting Key
red yellow red yellow
Function: Timer V2 on alarm in mode manned
1 2 min. Default off
2 3 min. on
3 4 min.
zone 1
on
4 5 min. on
5 6 min.
zone 2
on
LED zone 3 LED zone 4
6 7 min. on
7 8 min.
zone 3
on
8 9 min. on
9 10 min.
zone 4
on
Warning EN54-2 requires that the time V1 + V2 is no longer than 10 min.
