Siemens FC1008-A User Manual

Configuration
33
Building Technologies A6V10265083_a_en_--
Fire Safety & Security Products 03.2010
Basic programming steps
LED STEP Define function
1 Timer V1
2 Timer V2
3 Processing of zone Alarm (zone type)
4 LED activation mode
 LED Remote transmission
 LED Alarm
 LED System part disabled on mode manned
 No Resound or not on new alarm
5 Activation mode of control lines 1 - 6
6 Measures against false alarms
 alarm verification
 zone disabled in mode manned
7 Control lines on Alarm
on
8 Special zone parameters
 behavior on immediate Alarm after Reset
 function of zone control outputs
9 Not used
10 Detector line evaluation on line short or line break
11 Cross-zoning
12 Access code (password)
 operating access
13 Special PMI parameters
 reminder beep on fault and system part disabled
 Fault messages to be Reset
14 Not used
15 Special parameters
 external Acknowledge and Reset
 zones with special disabling procedure
 Remote transmission on operating access
 all zones with option 1 in step 3 react like option 4
flashing
16 Programmable control input
Do not assign functions cross zoning (step 11) and alarm verification (step 6) simultaneously to the
same zone!
Display programming steps
Step Define function
22 indicating mode display
 Function display mode
 Function alarm counter
23 switching mode manned/unmanned
24 display switching time
25 switching time summer/winter time
26 switching time manned/unmanned
 Time 1
 Time 2
