Siemens FC1008-A User Manual

Operation and indicator elements, mode of operation (PMI)
21
Building Technologies A6V10265083_a_en_--
Fire Safety & Security Products 03.2010
6 Operation and indicator elements, mode of opera-
tion (PMI)
6.1 Operating panel
6.1.1 General
The system operating panel is also called Person Machine Interface - PMI.
Overview operating functions
Related to Alarm Related to disable system parts Related to system test
 Acknowledge
 Reset
 Sounder/Resound
sounders
 Silence buzzer
 Cancel alarm delay
 Mode manned / un-
manned
cancel alarm delay
 Disable / Enable zones 1 to xx
 Disable / Enable alarm horn
 Disable / Enable fire controls
 Disable / Enable remote alarm
 Disable / Enable remote fault
 Mode detector test / Cancel
 Mode walk test / Cancel
 Test alarm horn for 30 sec.
 Simulation of zone alarm
 Simulation of zone fault
 Lamp test
 Service function
Operating access
Level 1 Operating functions always possible
Level 2 Operating functions accessible via access code or key switch
The default access code is 4233
– automatic time-out after 3 min
 set individual access code, preferably 6 digits
 disable access code if a key switch is used
Level 3 For user programming only, with additional access code
Level 4 Used to upload the panel software with additional equipment. The panel
needs to be open by removing the four allen screws.
Inscription stripes
 Label the individual zone texts in the Word template (available via hotline).
 Each zone LED must have a clear individual zone text, which indicates the geo-
graphical location of the corresponding detectors and / or manual call points.
 Inserting inscription stripes
