Siemens FC1008-A User Manual

Components and spare parts
45
Building Technologies A6V10265083_a_en_--
Fire Safety & Security Products 03.2010
11 Components and spare parts
11.1 Components
Type Part number Description Remarks
FC1008-A S54380-C4-A1 control unit 8 zones
FC1008-B S54380-C4-A10 control unit 8 zones GB
FC1008-C S54380-C4-A20 control unit 8 zones Nordic
FC1012-A S54380-C5-A1 control unit 12 zones
FC1012-B S54380-C5-A10 control unit 12 zones GB
FC1012-C S54380-C5-A20 control unit 12 zones Nordic
11.2 Accessories
Type Part number Description Remarks
FCA1003 S54380-C6-A1 control card
FCA1002 A6E60500021 display unit
Z3B171 4843830001 fire control relay 1 contact 250VDC/10A
FCA1007 A6E60500026 kit key switch incl. mounting instruc-
tion
FA2004-A1 A5Q00019354 FA2004-A1 battery 12V, 12 Ah, VDS
FA2005-A1 A5Q00019677 FA2005-A1 battery 12V, 17 Ah, VDS
11.3 Spare parts
Power supply
Type Part number Description Remarks
FP2001-A1 A5Q00005568-R Power supply (70 W)
FCA1014 A6E60500069 Battery holder
Electronic cards
Type Part number Description Remarks
FCM1008 S54380-C1-A10 Mainboard 8 zone
FCA1001 A6E60500020 Line extension card 4 zones
FCA1007-B A6E60500027 Line card GB
EOL
Type Part number Description Remarks
FCE1001 A6E60500031 EOL resistor 3k9 (dedector line) (set of 10 pieces)
FCE1003-B A6E60500033 EOL element GB
FCE1002 A6E60500032 EOL element control line
Cabinet cover
Type Part number Description Remarks
FCH1008 A6E60500038 Cover with PMI 8 zone
FCH1012 A6E60500043 Cover with PMI 12 zone
FCA1013 A6E60500068 Universal accessory bag
