Configuration
41
Building Technologies A6V10265083_a_en_--
Fire Safety & Security Products 03.2010
Display programming steps
Set options (parameter)
Selectable pre-settings
Programming steps and functions
Factory 1
2 3 4 5 6 7 8
Individual settings of a
selected pre-setting
22 indicating mode display
Function display mode
Function alarm counter
1
5
………………
………………
23 switching mode manned/unmanned 1 ………………
24 display switching time 1 ………………
25 switching time summer/winter time 1 ………………
26 switching time manned/unmanned
Time 1
Time 2
18:00
- -:- -
………………
………………
8.5 Checksum
Checksum to fill in when programming is completed
Without display module
Date of last changes LED 2 on LED 3 on LED 4 on LED 5 on LED 6 on LED 7 on Remarks
With display module
Year Date Time Checksum
