Operation and indicator elements, mode of operation (PMI)
26
Building Technologies A6V10265083_a_en_--
Fire Safety & Security Products 03.2010
6.2.3 Set clock
Set date and time
1. Give operating access on level 2
– the system may not display any alarm or fault
2. Hold key reset, key in 4233, release key reset and confirm by pressing key ac-
knowledge
– LED manned and operating access flash alternately and display shows
"1_.XX"
3. Set year with the numeric key 1 (>) or key 2 (>)
– confirm setting with zone key 1 then press key reset to proceed to next option
(month, day, etc.) or press key acknowledge to proceed to previous option
4. To end input sequence, press numeric key 4
– timeout 3min after last entry
– automatic stop after alarm or fault
Display Option Selection Setting digit 3 and 4
digit 1 digit 2 dot digit 3 digit 4
1 Year (03 to 99) 1 X X
2 Month (01 to 12) 2 X X
3 Day (01 to 31) 3 X X
4 Hour (00 to 23) 4 X X
5 Minute (00 to 59)
with numeric key 1 = up
with numeric key 2 = down
5
---
X X
6 Adjustment +/- 20sec per day key 1 to set clock 1-20sec faster
key 2 to set clock 1-20sec slower
6 - (-)
=
(+)
.
x x
It is only possible to go to the next option if the current entry is completed and ac-
cepted; otherwise, the buzzer will sound.
