Siemens SIMATIC IPC377E User Manual

Technical specifications
8.6 BIOS description
SIMATIC IPC377E
88 Operating Instructions, 2017/05, A5E40965249-AA
See options for CPU configuration below:
Option
Description
All
To enable all cores in CPU package.
1 To enable 1 core inside CPU package.
Note
For Quad core CPU, you can select to enable All/1 cores as you need. But for dual
-core
CPU, you can only select All
or 1.
USB Configuration
In USB configuration page, you can view and configure USB parameters.
USB device
The USB device shows the USB device detected by BIOS during POST. If there is no device
attached to the motherboard, only 2 Hubs is shown.
Legacy USB support
Follow the instruction below to enable or disable the USB support.
1. Select
Legacy
USB support
with the arrow keys and press
Enter
key.
2. Select
Enabled, Disabled
or
Auto
as you need and press
Enter
key in the active window
pop-up.
3. Press
F4
key and save the change.
See the options for legacy USB support below:
Option
Description
Auto
This option disables Legacy USB Support if there is no USB device is connected.
Enabled
This option enables Legacy USB Support.
Disabled
This option keeps USB device available only for EFI application.
USB3.0 Port 1,USB3.0 Port 2 and USB2.0 Ports
Follow the instruction below to enable or disable the USB Ports Per-port disable control.
1. Select
USB 3.0 Port 1
or
USB 3.0 Port 2
or
USB2.0 Ports
with the arrow keys and press
Enter
key.
2. Select
Enabled/Disabled
as you need and press
Enter
key in the active window pop-up.
3. Press
F4
key and save the change.
Note
If you select Disable
on
USB 2.0 Ports
, all the USB2.0 ports cannot be used.
