Technical specifications
8.6 BIOS description
SIMATIC IPC377E
Operating Instructions, 2017/05, A5E40965249-AA
89
Hardware Monitor
In hardware monitor page, you can view and monitor the hardware status. See the hardware
monitor parameters below:
Item
Description
system temperature
Show the temperature inside chassis.
CPU temperature Show the CPU temperature.
VCORE
Show VCORE power voltage.
+3.3V Show +3.3V power voltage.
+5V
Show +5V power voltage.
+12V
Show +12V power voltage.
VCC3V
Show VCC3V power voltage.
VSB3
Show VSB3 power voltage.
VBAT
Show VBAT power voltage.
SIO Configuration
In Super IO configuration page, you can view and configure super IO chip parameters.
Serial port 1 configuration
Follow the instruction below to enable or disable the serial port 1.
1. Select the port which you want to set with the arrow keys and press
Enter
key.
2. Select
Enabled
or
Disabled
as you need and press
Enter
key in the active window pop-
up.
3. The enabled port can select corresponding Change Setting and Device Mode and press
Enter
key.
4. Press
F4
key and save the change.
The table below is the detailed port setting.
Port type
Change Settings
Device Mode
Serial port 1 Auto
IO=3F8h; IRQ=4;
IO=2F8h; IRQ=3;
RS-232
RS-422
RS-485
Serial port 2 Auto
IO=2F8h; IRQ=3;
IO=3F8h; IRQ=4;
RS-232
RS-422
RS-485
Serial port 3 Auto
IO=3E8h; IRQ=11;
IO=2E8h; IRQ=11;
-
Serial port 4 Auto
IO=2E8h; IRQ=11;
IO=3E8h; IRQ=11;
-
