Siemens SIMATIC IPC377E User Manual

Technical specifications
8.6 BIOS description
SIMATIC IPC377E
90 Operating Instructions, 2017/05, A5E40965249-AA
Port type
Change Settings
Device Mode
Serial port 5 Auto
IO=2D0h; IRQ=11;
IO=2C0h; IRQ=11;
-
Serial port 6 Auto
IO=2C0h; IRQ=11;
IO=2D0h; IRQ=11;
-
See the options for device mode below:
Option
Description
RS-232
To enable RS-232 mode for serial port 1/2.
RS-422
To enable RS-422 mode for serial port 1/2.
RS-485
To enable RS-485 mode for serial port 1/2.
See the baud rate for RS-422 and RS-485 below: 50, 75, 110,134.5, 150, 300, 600, 1200,
1800, 2000, 2400, 3600, 4800, 7200, 9600, 19200, 38400, 57600, 115200.
Power Management
You can view and configure power management in this page.
Restore AC Power Loss
Follow the instruction below to enable or disable the AC power loss.
1. Select
Last State, Always On and Always Off
with the arrow keys and press
Enter
key.
2. Press
F4
key and save the change.
Resume from PME# / Resume from PCIE/RI
You can configure the IPC as the following instructions.
1. Select
Resume
PME#
or
Resume from PCIE/RI
with the arrow keys and press
Enter
key.
2. Select
Disabled
or
Enabled
as you need and press
Enter
key in the active window pop-
up.
3. Press
F4
key and save the change.
