Communication directions
from to Meaning
vlan x vlan x Access from IP subnet vlan x to IP subnet vlan x.
Example:
vlan1 (INT) → vlan2 (EXT)
Access from the local IP subnet to the external IP subnet.
ppp2 Access from the IP subnet to the WAN interface of the device.
Device Access from the IP subnet to the device.
SINEMA RC Access from the IP subnet to the SINEMA RC connection.
IPsec (all)
IPsec <Connection
Name>
OpenVPN (all)
OpenVPN <Connec‐
tion Name>
Access from the IP subnet to the VPN tunnel partners that can be reached
via all VPN connections (all) or via a certain VPN connection <Connection
Name>.
Device vlan x Access from the device to the IP subnet.
ppp2 Access from the device to the WAN interface of the device.
SINEMA RC Access from the device to the SINEMA RC connection.
IPsec (all)
IPsec <Connection
Name>
OpenVPN (all)
OpenVPN <Connec‐
tion Name>
Access from the device to the tunnel partners that can be reached via all
VPN connections (all) or via a certain VPN connection (<Connection
Name>).
SINEMA RC vlan x Access from SINEMA RC connections to the IP subnet.
ppp2 Access from the IP subnet to the WAN interface of the device.
Device Access from SINEMA RC connections to the device.
IPsec (all)
IPsec <Connection
Name>
OpenVPN (all)
OpenVPN <Connec‐
tion Name>
Access from the SINEMA RC server to the VPN tunnel partners that can be
reached via all VPN connections (all) or via a certain VPN connection
<Connection Name>.
IPsec (all)
IPsec <Connection
Name>
OpenVPN (all)
OpenVPN <Connec‐
tion Name>
vlan x Access via VPN tunnel partners to the IP subnet.
ppp2 Access from the IP subnet to the WAN interface of the device.
Device Access via VPN tunnel partners to the device.
SINEMA RC Access via VPN tunnel partners to the SINEMA RC connection.
Technical basics
3.5 Security functions
SCALANCE S615 Web Based Management
Configuration Manual, 11/2019, C79000-G8976-C388-08 43
