Siemens SIMATIC S5-95F - Page 367

S5-95F S5-95F on SINEC L1
Example: The S5-95F is to be a slave station and have the slave number 2 on the SINEC L1 bus.
Subunit A is interfaced to the L1 bus.
The following conditions apply to data transfer:
• Coordination byte UVB is flag byte 10
• Data is to be transmitted over data path 1 to slave 13 and 14
• Data is to be received over data paths 1 and 2 from slaves 13 and 14
• Slave 13 is an S5-115F programmable controller with CPU 942-7UF15 and slave 14 is an
S5-95F programmable controller
• The SINEC L1 safety time is 3 seconds for all connections
• If no valid frame can be received within the safety time, the S5-95F goes to STOP
Table 13-5. Initializing the Interface for Failsafe Data Interchange
Parameter in
the Default
DB
Description Value for the
Example
Permissible Values
SL1: Block ID "SINEC L1"
——
PGN N PG bus number
(required for executing
programmer functions over the
L1 bus; default value is NO)
PGN 1 PGN x
(x=1 to 30)
SLN N Slave number
Default value is NO
SLN 2 SLN x
(x=1 to 30)
SL1S: Block ID: "SINEC L1 failsafe"
——
UVB N User Valid Byte UVB MB 10 FY x
(x=0 to 255)
D1S N Data path 1 (send) is physically
interfaced to subunit ...; default
value is NO.
D1S A D1S k
k={N, A, B, H} where
Nˆ=no
Aˆ=subunit A
Bˆ=subunit B
Hˆ=subunits A and B
(high-availability
SINEC L1 bus)
D1E N Data path 1 (receive) is physically
interfaced to subunit ...; default
value is NO.
D1E A D1E k
D2S N
Data path 2 (send) is physically
interfaced to subunit ...; default
value is NO.
D2S A D2S k
D2E N
Data path 2 (receive) is physically
interfaced to subunit ...; default
value is NO.
D2E A D2E k
