S5-95F on SINEC L1 S5-95F
Table 13-5. Initializing the Interface for Failsafe Data Interchange (continued)
Parameters in
Default DB
Description Value for
Example
Permissible
Values
SNTS1 0 9 Slave no. and slave type to which
data is to be transmitted over
data path 1; default is no data
traffic
SNTS1 13 5 SNTS1 n t
n=1 to 31
0ˆ=No data traffic
1 ... 30 ˆ=Slave No.
31 ˆ= Broadcast
t={1, 5, 9} where
1ˆ=115F-14 mode
5ˆ=115F-15 mode
9ˆ=95F mode
SNTS2 0 9 Slave no. and slave type to which
data is to be transmitted over
data path 2; default is no data
traffic
SNTS2 14 9 SNTS2 n t
n
ˆ= Slave No. (1...30)
tˆ= Mode (1, 5, 9)
SNTE1 0 9 Slave no. and slave type from
which data is to be received over
data path 1; default is no data
traffic
SNTE1 13 5 SNTE1 n t
n
ˆ= Slave No. (1...30)
tˆ= Mode (1, 5, 9)
SNTE2 0 9 Slave no. and slave type from
which data is to be received over
data path 2; default is no data
traffic
SNTE2 14 9 SNTS2 n t
n
ˆ= Slave No. (1...30)
tˆ= Mode (1, 5, 9)
TD1S 0 Send safety time for data path 1 TD1S 17 TD1S u
u=0, 3 to 1638
(times 100 ms)
TD2S 0 Send safety time for data path 2 TD2S 17 TD2S u
TD1E 0 S
Receive safety time for data
path 1 and PLC response
TD1E 30 S TD1E u p
p={S, P} where
S=STOP
P=Passivation of the
data paths with
response on user
level
TD2E 0 S Receive safety time for data
path 2 and PLC response
TD2E 30 S TD2E u p
