Siemens SIMATIC S7-300 Module data User Manual

Digital modules
3.32 Digital IO module SM 323; DI 16/DO 16 x DC 24 V/0.5 A; (6ES7323-1BL00-0AA0)
S7-300 Automation System Module data
3-114 Manual, 08/2006, A5E00105505-04
Technical data of SM 323; DI 16/DO 16 x DC 24 V/0.5 A
Technical data
Dimensions and weight
Dimensions W x H x D (mm) 40 x 125 x 117
Weight approx. 260 g
Module-specific data
Isochronous No
Number of inputs 16
Number of outputs 16
Cable length
• unshielded
• shielded
max. 600 m
max. 1000 m
Voltages, currents, electrical potentials
Rated load voltage L+ 24 VDC
Number of simultaneously controlled inputs
• horizontal mounting position
up to 40 °C
up to 60 °C
16
8
• vertical mounting position
up to 40 °C
16
Cumulative current of outputs (per group)
• horizontal mounting position
up to 40 °C
up to 60 °C
max. 4 A
max. 3 A
• vertical mounting position
up to 40 °C
max. 2 A
Electrical isolation
• between channels and the backplane bus
Yes
• between channels
Inputs in groups of
Outputs in groups of
Yes
16
8
Permissible potential difference
• between different circuits
75 VDC / 60 VAC
Isolation test voltage 500 VDC
Current consumption
• from the backplane bus
• from load voltage L+ (no-load)
max. 80 mA
max. 80 mA
Power loss of the module typ. 6.5 W
Status, interrupts, diagnostics
Status display green LED per channel
Interrupts None
Diagnostics functions None

Siemens SIMATIC S7-300 Module data Specifications

General

Series	S7-300
Manufacturer	Siemens
Protection Class	IP20
System	SIMATIC S7-300
Digital Inputs	Varies by module
Digital Outputs	Varies by module
Analog Inputs	Varies by module
Analog Outputs	Varies by module
Central Processing Unit	Varies by CPU model
Supply Voltage	24V DC or 120/230V AC
CPU Type	Varies (e.g., CPU 312, CPU 315, etc.)
Memory	Varies by CPU model
Communication Interfaces	MPI, PROFIBUS
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Relative Humidity	10% to 95% (non-condensing)
