Siemens SIMATIC S7-300 Module data User Manual

Digital modules
3.32 Digital IO module SM 323; DI 16/DO 16 x DC 24 V/0.5 A; (6ES7323-1BL00-0AA0)
S7-300 Automation System Module data
Manual, 08/2006, A5E00105505-04
3-115
Technical data
Transducer selection data
Input voltage
• Rated value
• for "1" signal
• for "0" signal
24 VDC
13 to 30 V
- 30 V to + 5 V
Input current
• with "1" signal
typ. 7 mA
Input delay
• at "1" to "0"
• at "1" to "0"
1.2 ms to 4.8 ms
1.2 ms to 4.8 ms
Input characteristics to IEC 61131, type 1
Connection of 2-wire BEROs
• Permissible quiescent current
supported
max. 1.5 mA
Wiring signal transducers with 40-pin front connector
Actuator selection data
Output voltage
• with "1" signal
min. L + (- 0.8 V)
Output current
• with "1" signal
Rated value
Permissible range
0.5 A
5 mA to 0.6 A
• with "0" signal (residual current)
max. 0.5 mA
Output delay (resistive load)
• at "1" to "0"
• at "1" to "0"
max. 100 μs
max. 500 μs
Load resistance range 48 Ω to 4 kΩ
Lamp load max. 5 W
Wiring two outputs in parallel
• for redundant load control
supported (only outputs of the same group)
• for performance increase
not supported
Control of a digital input supported
Switching frequency
• with resistive load
• with inductive load to IEC 947-5-1, DC 13
• with lamp load
max. 100 Hz
max. 0.5 Hz
max. 10 Hz
Internal limiting of the inductive shutdown voltage to typ. L + (- 53 V)
Short circuit-proof output Yes, electronic
• Threshold
typ. 1 A
Wiring the actuators with 40-pin front connector
