Product Information on the Manual
A5E00201782-03
Module
Peculiarities when reparameterizingBehavior of the
inputs/outputs
6ES7 332-5HD01-0AB0
SM 332; AO 4 12 Bit
Output the last valid
output value before
ti ti
SF LED shines:
If there was a pending diagnosis before
reparameterization, the SF LEDs (on the
CPU, IM, or module) may still be shining
although there is no longer a pending
dia
g
nosis and the module is workin
g
6ES7 332-5HB01-0AB0
6ES7 332-5HB81-0AB0
SM 332; AO 2 12 Bit
parameterization
diagnosis and the module is working
correctly.
Remedy:
• Only reparameterize when there is no
pending diagnosis on the module, or
• Remove the module, and then plug it in
again
6ES7 332-5HF00-0AB0
SM 332; AO 8 12 Bit
---
6ES7 332-7ND00-0AB0
6ES7 332-7ND01-0AB0
SM 332; AO 4 16 Bit
---
Module
Behavior of the
inputs/outputs
Peculiarities when reparameterizing
ET 200M signal modules for process automation (PCS7)
6ES7 321-7TH00-0AB0
SM 321; DI 16 NAMUR
Supply the last valid
process value (including
the value status) before
parameterization
SF LED shines:
If there was a pending diagnosis before
reparameterization, the SF LEDs (on the
CPU, IM, or module) may still be shining
although there is no longer a pending
diagnosis and the module is working
correctly.
Remedy:
6ES7 322-8BH00-0AB0
SM 322; DO 16 DC 24
V/0,5A
Output the last valid
output value before
parameterization
Remedy:
• Only reparameterize when there is no
pending diagnosis on the module, or
• Remove the module, and then plug it in
again
