EIP-200S Ethernet/IP Adapter
2.7 Device profile: vendor-specific objects
EIP-200S Ethernet/IP Adapter Distributed I/O System
44 System Manual, 06/2018, A5E44345053-AB
Attribute
ID
Access rule
Name
Data type
Data value
20
Get/Set
2
HeadParamByte11
USINT
21 Get/Set
2
HeadParamByte12 USINT
22
Get/Set
2
HeadParamByte13
USINT
23
Get/Set
2
HeadParamByte14
USINT
24
Get/Set
2
HeadParamByte15
USINT
25
Get/Set
2
HeadParamByte16
USINT
26
Get/Set
2
HeadParamByte17
USINT
27
Get/Set
2
HeadParamByte18
USINT
28
Get/Set
2
HeadParamByte19
USINT
29
Reserved
30
Reserved
31
Reserved
32 Get Firmware version
String Length
ASCII String
Struct of:
USINT
STRING
Firmware version
33 Get Serial Number
String Length
ASCII String
Struct of:
USINT
STRING
Serial number
1
Length of data [...] array does not include data.
2
When an I/O connection is open: setting this attribute returns Device_State_Conflict.
Attribute 1 [AdapterStatus] details
Object
0x64
Instance
0x01
Attribute
0x06
Size
65
The AdapterStatus attribute reports the status of the EIP-200S Ethernet/IP Adapter and
electronic modules:
Bit(s)
Name
Description
0
Reserved
1 Parameters rejected One or more modules rejected the parameters
specified by its slot object.
2 Configuration rejected One or more modules rejected the configuration
byte specified by its slot object.
3
Electronic module diagnostics
One or more modules is reporting an error.
4 - 7
Reserved
