Siemens SIMATIC S7 EIP-200S User Manual

EIP-200S Ethernet/IP Adapter
2.6 Device profile: supported CIP objects
EIP-200S Ethernet/IP Adapter Distributed I/O System
System Manual, 06/2018, A5E44345053-AB
31
2.6.4
TCP/IP Interface Object
The TCP/IP Interface Object provides the mechanism to configure the EIP200S Ethernet/IP
Adapter’s TCP/IP network interface. Examples of configurable items include the device's
IP address, network mask, gateway address, and host name.
Class attributes
1, 2, 3
Class services
0x1, 0xE, 0x10
Instance attributes
1, 2, 3, 4, 5, 6, 12, 13
Instance services
0x1, 0xE, 0x10
Class attributes for TCP/IP Interface Object
Attribute
ID
Access
rule
Description
Data type
Default val-
ue
1
Get
Revision
UINT
0x0001
2
Get
Maximum number of instances
UINT
0x0001
3
Get
Number of instances
UINT
0x0001
