2.6 Device profile: supported CIP objects
EIP-200S Ethernet/IP Adapter Distributed I/O System
System Manual, 06/2018, A5E44345053-AB
35
2.6.5
Ethernet Link Object
The Ethernet Link Object maintains link-specific counters and status information for an
IEEE 802.3 communications interface. The EIP-200S Ethernet/IP Adapter has an embedded
2-port switch and has two instances of the Ethernet Link Object (one for each port).
Class attributes
1, 2, 3
Class services
0x1, 0xE, 0x10
Instance attributes
1, 2, 3, 4, 5, 6, 7, 8, 10, 11
Instance services
0x1, 0xE, 0x10
Number of instances
2
Class attributes for Ethernet Link Object
Attribute
ID
Access
rule
Name
Description
Data type
Semantics of values
1 Get Revision Revision of this object UINT 1 = the minimum value.
≥ 2 = if instance attribute 6
is implemented.
3 = the maximum value.
2 Get Max In-
stance
Maximum instance num-
ber of an object currently
created in this class level
of the device
UINT The largest instance num-
ber of a created object at
this class hierarchy level.
3 Get Number of
Instances
Number of object instanc-
es currently created at
this class level of the
device
UINT The number of object in-
stances at this class hier-
archy level.
Instance 1 attributes for Ethernet Link Object
Attribute
ID
Access
rule
Name
Description
Data type
Semantics of values
1 Get Interface
Speed
Interface speed cur-
rently in use
UDINT Speed in Mbps (10, 100,
etc.).
2 Get Interface
Flags
Interface status flags DWORD Bit map of interface flags.
See Table "Interface Flags
attribute" below.
3 Get Physical
Address
MAC layer address ARRAY
of 6
USINTs
MAC layer address
in the format
"XX-XX-XX-XX-XX-XX."
4 Get Interface
Counters
Relevant to the receipt
of packets
STRUCT
of:
See section "Interface
Counters" below.
5 Get Media
Counters
Media-specific counters STRUCT
of:
See section "Media Coun-
ters" below.
