EIP-200S Ethernet/IP Adapter
2.6 Device profile: supported CIP objects
EIP-200S Ethernet/IP Adapter Distributed I/O System
28 System Manual, 06/2018, A5E44345053-AB
2.6.2
Assembly Object
The following applies to the Assembly Object for the EIP-200S Ethernet/IP Adapter.
Class code
0x04
Class attributes
1, 2, 3
Number of instances
4
Class attributes for Assembly Object
Attribute
ID
Access
rule
Description
Data type
Default val-
ue
1
Get
Revision of this object
UINT
0x0002
2
Get
Maximum instance
UINT
0x0069
3
Get
Number of instances
UINT
0x0004
Instance attributes for Assembly Object:
Instance 101 (65
hex
): Input Assembly
Attribute
ID
Access
rule
Description
Data type
Default
value
3
Get
Input Data
ARRAY of BYTE
---
Instance 102 (66
hex
): Output Assembly
Attribute
ID
Access
rule
Description
Data type
Default
value
3
Set
Output Data
ARRAY of BYTE
---
Instance 103 (67
hex
): Config Assembly
Attribute
ID
Access
rule
Description
Data type
Default
value
3
Get
Configuration data
ARRAY of BYTE
---
Instance 198 (C6
hex
): Input Only
This instance is used to establish a connection when no outputs are to be addressed or
when inputs, which are already being used in an exclusive owner connection, are to be
interrogated. The data length of this instance is always zero.
