Siemens SIMATIC S7 EIP-200S User Manual

EIP-200S Ethernet/IP Adapter Distributed I/O System
System Manual, 06/2018, A5E44345053-AB
15
EIP-200S Ethernet/IP Adapter
2
Hardware configuration
See the separate manual "EIP ET200 Configuration Tool User Manual" for information on
the EIP ET200 Configuration Tool for the EIP-200S Ethernet/IP Adapter. The manual can be
found on the Companion Disk that shipped with the product, or downloaded from the
Siemens Service & Support Website (http://support.automation.siemens.com).
LED status indicators
The EIP-200S Ethernet/IP Adapter module has three bi-color LEDs that provide diagnostic
information about the current state of the device and provide an indication of any faults. The
LEDs conform to the behaviors defined in the ODVA Ethernet/IP Adaptation of CIP Adapter
Specification for the Module Status and Network Status LEDs, and in this manual for I/O
Status LEDs.
LED status indicator: Module Status LED
The bi-color Module Status LED indicates the current state of the EIP-200S Ethernet/IP
Adapter, as described in the following table:
State
Description
Off
No power applied to device.
Flashing green Device has not been configured.
Invalid parameter data.
Green Device has initialized successfully and no errors
were detected.
Flashing red Recoverable fault.
Device needs commissioning due to configuration
error:
• Invalid parameter data
• Invalid slot configuration data.
Red
Unrecoverable fault detected: hardware failure.
