EIP-200S Ethernet/IP Adapter
2.7 Device profile: vendor-specific objects
EIP-200S Ethernet/IP Adapter Distributed I/O System
System Manual, 06/2018, A5E44345053-AB
47
Common services for the Adapter Object
The following information applies to the Slot Object for the EIP-200S Ethernet/IP Adapter.
The Slot Object provides the external configuration and monitoring interface to the I/O
module in one slot. One instance of this object exists for each available slot.
No attributes are supported for the Slot Object at the class level.
Instance attributes of the Slot Object
1 Get / Set
1,2
ModuleRefer-
UINT For Configuration Tool use.
2 Get / Set
1,2
ParameterSize USINT Number of parameter bytes required by this
slot (max. 32).
3 Get / Set
1,2
Parameters Array of
Parameter bytes for this slot: array size is set
1,2
Configuration byte for this slot.
Slot status code (see Attribute 5 table).
Channel Status code (see Attribute 6-13
table).
