Installation and wiring
3.5 Wiring and setup
EIP-200S Ethernet/IP Adapter Distributed I/O System
System Manual, 06/2018, A5E44345053-AB
59
Wiring and setup
Prewiring
The ET 200S distributed I/O system allows you to prewire the terminal modules with
screw-type or spring terminals.
General rules and regulations for operating the EIP-200S
Ethernet/IP Adapter
Introduction
When operating the ET 200S distributed I/O system as a component part of a plant or
system, certain rules and regulations have to be followed depending on where the device is
to be used.
This chapter provides an overview of the most important rules you have to observe when
integrating the ET 200S in a plant or system.
Note the safety and accident prevention regulations that apply to specific applications (for
example, the Machine Directive).
Emergency stop devices complying with IEC 204 (which corresponds to DIN VDE 0113)
must remain effective in all the operating modes of the plant or system.
Startup of the system after specific events
The following table tells you what you should do when the system starts up after the
occurrence of specific events:
• Startup follows a voltage drop or failure, or
• Startup of the ET 200S follows an interruption
of bus communication
No dangerous operating states must occur. If
necessary, force an emergency stop.
• Startup follows unlocking of the emergency
stop device
There must not be an uncontrolled or undefined
startup.
