Siemens SIMATIC S7 EIP-200S User Manual

EIP-200S Ethernet/IP Adapter Distributed I/O System
System Manual, 06/2018, A5E44345053-AB
107
Address space of the ET 200S inputs and outputs
C
Address area of the modules
The following table shows address area inputs and outputs for the ET 200S.
Module
Address space of the inputs
Address space of the outputs
Without group-
ing
With grouping
1
Without group-
ing
With grouping
1
Digital input modules 1 byte 2 bits (2DI)
4 bits (4DI)
--- ---
1 byte (8DI)
Digital output modules --- --- 1 byte 2 bits (2DO)
4 bits (4DO)
1 byte (8DO)
NAMUR input
2 bytes
—
Analog input modules
4 bytes
---
---
Analog output modules --- --- 4 bytes
Direct-on-line starter
1 byte
4 bits
1 byte
4 bits
Reversing starter
1 byte
4 bits
1 byte
4 bits
1
See the section "Configuring the ET 200S"
