Siemens SIMATIC S7 EIP-200S User Manual

Installation and wiring
3.9 Wiring the ET 200S
EIP-200S Ethernet/IP Adapter Distributed I/O System
System Manual, 06/2018, A5E44345053-AB
65
3.9
Wiring the ET 200S
3.9.1
Wiring rules for the ET 200S
Wiring rules for:
Interface voltage
(supply voltage)
Terminal modules
(spring and screw-
type terminals)
Terminal modules
(Fast Connect)
Connectable wire cross-sections for
rigid lines
No 0.14 to 2.5 mm
2
0.5 to 1.5 mm
2
Connectable wire
cross-sections for
flexible lines
Without wire end
ferrule
0.25 to 2.5 mm
2
0.14 to 2.5 mm
2
0.5 to 1.5 mm
2
With wire end
ferrule
0.25 to 1.5 mm
2
0.14 to 1.5 mm
2
---
Number of wires per connection 1 or a combination of 2 wires up to
1.5 mm
2
(sum) in a common wire end
ferrule
1
Maximum external diameter of the
wire’s insulation
∅ 3.8 mm ∅ 3.1 mm at
1.5 mm
2
∅ 3.8 mm at
2.5 mm
2
∅ 3.2 mm at
1.5 mm
2
Stripping length of the wires
11 mm
---
Wire end ferrules
to DIN 46228
Without insulating
collar
Form A, 8 to
12 mm long
Form A, up to
12 mm long
---
With insulating
collar 0.25 to
1.5 mm
2
Form B, up to 12 mm long ---
3.9.2
Wiring a terminal module with screw-type terminals
Features
In terminal modules with screw-type terminals, the individual wires are screwed into the
terminal.
No wire end ferrules are required.
Prerequisites
Adhere to the wiring rules.
Tool required
3 mm screwdriver
