Installation and wiring
3.6 General rules and regulations for operating the EIP-200S Ethernet/IP Adapter
EIP-200S Ethernet/IP Adapter Distributed I/O System
60 System Manual, 06/2018, A5E44345053-AB
Line voltage
The following table tells you what you should do with regard to the line voltage:
With:
Requirements:
Permanently installed plants or systems without
all-pole line disconnect switches
There must be a line disconnect switch or a fuse
in the building installation system.
Load power supplies, power supply modules The set rated voltage range must correspond to
the local line voltage.
All circuits of the ET 200S distributed I/O system Any fluctuation/deviation in the line voltage from
the rated value must be within the permitted tol-
erances.
24 VDC supply
The following table tells you what you should do with regard to the 24 VDC supply:
With:
Pay attention to:
Buildings
Outdoor lightning protection
Take lightning protection pre-
cautions
(for example, lightning conduc-
tors)
24 VDC supply lines, signal
lines
Indoor lightning protection
24 VDC supply
Safe (electrical) isolation of extra-low voltage
Protection against outside electrical influences
The following table tells you what to do to provide protection against electrical influences or
faults:
With:
You must ensure that:
All plants or systems in which the ET 200S is
integrated
The plant or system is connected to a protective
conductor for diverting electromagnetic interfer-
ence.
Supply, signal, and bus lines The wiring arrangement and installation are cor-
rect.
Signal and bus lines Any break of a line or conductor does not result in
undefined states of the plant or system.
