EIP-200S Ethernet/IP Adapter
2.6 Device profile: supported CIP objects
EIP-200S Ethernet/IP Adapter Distributed I/O System
System Manual, 06/2018, A5E44345053-AB
27
Extended Device Status - Bits 4-7
Bits 4-7
Extended Device Status Description
0 0 0 0
Self-testing or Unknown.
0 0 0 1 Firmware update in progress.
0 0 1 0
At least one faulted I/O connection.
0 0 1 1
No I/O connections established.
0 1 0 0
Nonvolatile configuration bad.
0 1 0 1
Major fault - either bit 10 or bit 11 is true (1).
0 1 1 0
At least one I/O connection in run mode.
0 1 1 1
At least one I/O connection established, all in idle mode.
1 0 0 0
1 0 0 1
Reserved, shall be 0.
1 0 1 0 thru 1 1 1 1
Vendor/product specific.
Note
Behavior after a fault
A device may not be able to communicate in the Major Unrecoverable Fault state. Therefore,
it might not be able to report a Major Unrecoverable Fault. It will not process a Reset service.
The only exit from a Major Unrecoverable Fault is to cycle power.
Common services for Identity Object
Service code
Implemented for
Service name
Class
Instance
0x0E
Yes
Yes
Get_Attribute_Single
0x05
Yes
Yes
Reset
0x01
Yes
Yes
Get_Attributes_All
