2.6 Device profile: supported CIP objects
EIP-200S Ethernet/IP Adapter Distributed I/O System
26 System Manual, 06/2018, A5E44345053-AB
Device_Status definitions for Identity Object
Bit(s)
Called
Definition
0 Owned 0 = not owned
1 = the device has an owner
1
Reserved
Always 0
2 Configured 0 = "out-of-box" configuration
1 = configuration modified (not including
communications)
3
Reserved
Always 0
4, 5, 6, 7 Extended Device Status Defined in the table "Extended device sta-
tus description" below
8
Minor recoverable fault
Minor configuration fault
9
Minor unrecoverable fault
Minor device fault (unrecoverable)
10
Major recoverable fault
Major configuration fault
11
Major unrecoverable fault
Major device fault (unrecoverable)
12, 13
Reserved
Always 0
14, 15
Reserved
Always 0
Extended device status description
Bit(s)
Called
Definition
0 Owned TRUE indicates the device (or an object within the device) has an own-
er.
1
Reserved, shall be 0.
2 Configured TRUE indicates the application of the device has been configured to do
something different than the "out-of-box" default. This shall not include
configuration of the communications.
3 Reserved, shall be 0.
4 - 7 Extended Device
Status
See "Extended Device Status - Bits 4-7" table below.
8 Minor Recoverable
Fault
TRUE indicates the device detected a problem with itself, which is
thought to be recoverable. The problem does not cause the device to
go into one of the faulted states. See Note regarding Behavior below.
9 Minor Unrecovera-
ble Fault
TRUE indicates the device detected a problem with itself, which is
thought to be unrecoverable. The problem does not cause the device to
go into one of the faulted states. See Note regarding Behavior below.
10 Major Recoverable
Fault
TRUE indicates the device detected a problem with itself, which caused
the device to go into the "Major Recoverable Fault" state. See Note
regarding Behavior below.
11 Major Unrecovera-
ble Fault
TRUE indicates the device detected a problem with itself, which caused
the device to go into the "Major Unrecoverable Fault" state. See Note
regarding Behavior below.
12-15
Reserved, shall be 0.
