An overview of system components
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
79
System component,
accessory
MLFB
Diagram
for
pro C
for
pro S
for V
PN GP
for pro
V PB
for
pro V MB
RTU
for
pro V
PN
for
pro V
EIP
Covers for screwed
connection:
between contactor and
current measuring
module or
between
current/voltage
measuring module with
direct mounting
can be used for
3UF7 1.3-1BA00-0
can be used for
3UF7 1.4-1BA00-0
3RT1956-4EA3
3RT1966-4EA3
Box terminal blocks
for round and ribbon
cable conductors
up to 70 mm2, can be
used for
3UF7 1.3-1BA00-0
up to 120 mm2, can be
used for
3UF7 1.3-1BA00-0
up to 240 mm2, can be
used for
3UF7 1.4-1BA00-0
3RT1955-4G
3RT1956-4G
3RT1966-4G
Bus termination module
with dedicated power
supply;
for bus connection after
the last device on the
bus
Supply voltage:
115/230 V AC
24 V DC
Note
The use of bus
connection modules is
recommended, in
particular, when using
SIMOCODE pro S.
3UF1900-1KA00
3UF1900-1KB00
Bus connecting
terminal
For securing the
PROFIBUS cable on
the SIMOCODE pro S
basic unit.
3UF7960-0AA00-0
1) For basic unit SIMOCODE pro V PB from version *E09*
