Configuration
5.4 Mounting
1FW3 complete torque motors
142 Configuration Manual, 08/2020, A5E46027705B AA
Before mounting, remove the encoder including the transport ring according to the following
description "Removing/mounting the encoder".
Note
Comply with the mounting conditions
In order that the motor operates correctly, already when designing the machine or the
system, it is absolutely mandatory that the mounting conditions are complied with acc
ording
to dimension drawing 609.30284.01. The sum of all of the tolerances of the
mounting must
not exceed the tolerances listed under L
2
.
This includes, for example:
Positioning the motor shaft when mounting
Shifting the customers shaft
Thermal expansion of the customer's shaft
