Siemens SIMOTICS T-1FW3 User Manual

1FW3 complete torque motors
Configuration Manual, 08/2020, A5E46027705B AA
91
Configuration
5
5.1 Configuring software
5.1.1 SIZER configuration tool
Overview
The SIZER calculation tool supports you in the technical dimensioning of the hardware and
firmware components required for a drive task.
SIZER supports the following configuration steps:
● Configuring the power supply
● Designing the motor and gearbox, including calculation of mechanical transmission
elements
● Configuring the drive components
● Compiling the required accessories
● Selection of the line-side and motor-side power options
The configuration process produces the following results:
● A parts list of components required (Export to Excel)
● Technical specifications of the system
● Characteristic curves
● Comments on system reactions
● Installation information of the drive and control components
● Energy considerations of the configured drive systems
You can find additional information that you can download in the Internet at SIZER
(https://support.industry.siemens.com/cs/ww/en/view/54992004).
The STARTER commissioning tool offers
● Commissioning
● Optimization
● Diagnostics
Table 5- 1 Article number for STARTER
Commissioning tool Article no. of the DVD
STARTER
German, English, French, Italian, Spanish
6SL3072-0AA00-0AG0
5.1.2
STARTER drive/commissioning s
oftware
