Siemens SIMOTICS T-1FW3 User Manual

1FW3 complete torque motors
Configuration Manual, 08/2020, A5E46027705B AA
313
Installation drawings/Dimension drawings
9
Note
Motor dimensions
Siemens reserves the right to change the motor dimensions as part of design improvements
without prior n
otification. The dimension drawings provided in this documentation, therefore,
may not necessarily be up to date.
You can request up
-to-date dimension drawings at no charge.
9.1 CAD-Creator/DT-Configurator
CAD CREATOR
In the CAD CREATOR you will find the following quickly and easily:
● Dimension drawings
● 2D/3D CAD data
The CAD CREATOR supports you in the creation of system documentation regarding
project-specific information. The data for motors, drives and CNC controls is currently
available in the online version.
Note
The 3D model in the CAD CREATOR is a simplified representation that does not display
every detail.
You will find further information on the Internet at "CAD CREATOR
(http://www.siemens.com/cadcreator)".
Motors
● 1FK7, 1FT7, 1FT6 synchronous motors
● 1FE1 built-in synchronous motors
● 1FW3 complete torque motors
● 1FW6 built-in torque motors
● 1FK7, 1FT7, 1FT6 geared motors
● 1PH8 synchronous/induction motors
● 1PH7, 1PH4, 1PL6, 1PM4, 1PM6 induction motors
