Siemens SIMOTICS T-1FW3 User Manual

Motor components and options
4.1 Motor components
1FW3 complete torque motors
84 Configuration Manual, 08/2020, A5E46027705B AA
4.1.2.5 Absolute encoders
Description of multiturn absolute encoders
This encoder outputs an absolute angular position between 0° and 360° in the specified
resolution. An internal measuring gearbox enables the encoder to differentiate between 4096
revolutions.
Description, absolute value singleturn
This encoder outputs an absolute angular position between 0° and 360° in the specified
resolution. Contrary to a multiturn absolute encoder, the encoder has no measuring gearbox
and can therefore only supply the position value within one revolution.
Function and technical data
● Angular measuring system for the commutation
● Speed actual value sensing
● For single-turn encoders: indirect measuring system for absolute position sensing within a
traversing range of 1 revolution
● For multi-turn encoders: indirect measuring system for sensing the absolute position
within a traversing range of 4096 revolutions
Table 4- 7 Technical specifications, absolute encoder
Encoder type
9
th
position in
the Article No.
Operating
voltage
Max. current
consumption
Absolute reso-
lution (single-
turn)
Travers-
ing-range
(multiturn)
A-B track: Resolu-
tion incremental
(sin/cos periods per
revolution)
Angular
error
without DRIVE-CLiQ interface
Absolute encoder
2048 S/R, (4096 revolu-
tions, multi-turn, with
EnDat interface 2.1
E 5 V ± 5 % 200 mA --- 4096
(= 12 bits)
2048 S/R (1 V
pp
) ± 40"
with DRIVE-CLiQ interface
Absolute encoder, single-
turn, 24 bit
B 24 V 110 mA 16777216
(= 24 bits)
--- --- ± 40"
Absolute encoder
24 bit + 12 bit multiturn
C 24 V 110 mA 16777216
(= 24 bits)
4096
(= 12 bits)
--- ± 40"
Absolute encoder single-
turn 22 bit + 12 bit multi-
turn
F 5 V ± 5 % 200 mA 4194304
(= 22 bits)
4096
(= 12 bits)
--- ± 40"
