Description of the motor
2.3 Technical features and environmental conditions
1FW3 complete torque motors
Configuration Manual, 08/2020, A5E46027705B AA
23
● Roll drives in paper machines
● Cross-cutter drives for continuous material webs, e.g. paper, textiles, metal sheet
● Wire-drawing machines
● Chippers
WARNING
Injury and material damage by not observing machinery directive 2006/42/EC
There is a risk of death, serious injury and/or material damage if machinery directive
2006/42/EC is not carefully observed.
• The products included in the scope of delivery are exclusively designed for installation in
a machine. Commissioning is prohibited until it has been fully established that the end
product conforms with machinery directive 2006/42/EC.
• Observe all safety instructions and provide these safety instructions to the end user.
2.3 Technical features and environmental conditions
2.3.1 Directives and standards
Standards that are complied with
The motors of the type series SIMOTICS S, SIMOTICS M, SIMOTICS L, SIMOTICS T,
SIMOTICS A, called "SIMOTICS motor series" below, fulfill the requirements of the following
directives and standards:
● EN 60034-1 - Rotating electrical machines – Dimensioning and operating behavior
● EN 60204-1 - Safety of machinery – Electrical equipment of machines; general
requirements
Where applicable, the SIMOTICS motor series are in conformance with the following parts of
EN 60034:
Feature
Standard
Degree of protection
EN 60034-5
Cooling
1)
EN 60034-6
Type of construction
EN 60034-7
Connection designations
EN 60034-8
Noise levels
1)
EN 60034-9
Temperature monitoring
EN 60034-11
Vibration severity grades
1)
EN 60034-14
1)
Standard component, e.g. cannot be applied to built-in motors
