1FW3 complete torque motors
Configuration Manual, 08/2020, A5E46027705B AA
293
7.1 Transporting
Danger to life when lifting and transporting
Incorrect execution, unsuitable or damaged devices and equipment can result in severe
injury and/or material damage.
• Lifting devices, forklift trucks and load suspension equipment must comply with country-
specific, local requirements.
• Pay attention to the lifting capacity of the hoisting gear. Do not attach any additional
loads. Take the weight of the motor from the rating plate.
• To hoist the motor, use suitable cable-guidance or spreading equipment (particularly if
additional components are mounted in or on the motor).
• After the motor has been placed down, ensure that it cannot roll.
Damage to the motor caused by incorrect lifting
The motor can be damaged if you incorrectly use lifting equipment.
• Use a cross beam when lifting and transporting the motor using the cable slings
provided.
Figure 7-1 Lifting and transporting the motor with a cross beam
If you do not immediately commission a motor after it has been delivered, it must be stored
in a dry, dust-free room that is not subject to vibration, see Chapter "Storing (Page 294)".
