Siemens SIMOTICS T-1FW3 User Manual

Description of the motor
2.3 Technical features and environmental conditions
1FW3 complete torque motors
28 Configuration Manual, 08/2020, A5E46027705B AA
2.3.4 Environmental conditions
You can classify the ambient conditions for stationary use at weather-protected locations
according to standard DIN IEC 60721-3-3. The environmental effects and their limit values
are defined in various classes in this standard.
With the exception of "Condensation" and "Low air pressure" environmental parameters, you
can assign SIMOTICS T-1FW3 complete torque motors to climatic class 3K4. Condensation
and expansion of the temperature range are not permissible.
Table 2- 3 Environmental conditions are based on climate class 3K4
Environmental parameter
Unit
Value
a)
Low air temperature
°C
- 15
b)
High air temperature
°C
+ 40
c)
Low relative humidity
%
5
d) High relative humidity % 95
e)
Low absolute humidity
g/m
3
1
f)
High absolute humidity
g/m
3
29
g)
Rate of temperature change
1)
°C/min
0.5
h)
Low air pressure
5)
kPa
89
i)
High air pressure
2)
kPa
106
j)
Solar radiation
W/m
2
700
k)
Thermal radiation
-
-
l)
Air movement
4)
m/s
1.0
m)
Condensation
-
Not permissible
n) Wind-driven precipitation
(rain, snow, hail, etc.)
- -
o) Water (other than rain) - See protection
class
p)
Formation of ice
-
-
1)
Averaged over a period of 5 min
2)
Conditions in mines are not considered.
3)
Climate-controlled locations with a tolerance of ±2 °C, referred to defined limit values.
4)
A cooling system based on natural convection can be disturbed by unforeseen air movements.
5)
The limit value of 89 KPa covers altitudes up to1000 m.
Note
Additional data on the ambient conditions
You will find additional data on the ambient conditions, such as ambient temperatures or
conditions for transport and storage of the motors, in the relevant chapters of this
documentation.
