Installation drawings/Dimension drawings
9.2 Dimension drawings
1FW3 complete torque motors
334 Configuration Manual, 08/2020, A5E46027705B AA
9.2.4 Heavy Duty
You can find information on "Heavy Duty" in Chapter "Heavy Duty (Z option L03)
(Page 149)".
Figure 9-11 SH200, Heavy Duty
