Siemens SIMOTICS T-1FW3 User Manual

Installation drawings/Dimension drawings
9.2 Dimension drawings
1FW3 complete torque motors
320 Configuration Manual, 08/2020, A5E46027705B AA
Table 9- 5 Motor table
version
l
c
d
e
f
weight
[mm]
[mm]
[mm]
[mm]
[mm]
[kg]
1FW3281
574.0
483.5
258.0
571.0
393.0
600
1FW3283
658.5
568.0
342.5
655.5
477.5
690
1FW3285
784.5
694.0
468.5
781.5
603.5
860
1FW3287
953.0
862.5
637.0
950.0
772.0
1030
Table 9- 6 Table terminal box
version (cable outlet
direction)
thread
h
W
g
a x b
[mm]
[mm]
[mm]
[mm]
1XB7-700
3x M75x1.5
743
684
363
306 x 306
1XB7-712 (axial
DE)
4x M75x1.5 836 764 354 371 x 370
1XB7-712 (axial
NDE)
4x M75x1.5 836 764 385 371 x 370
1XB7-712 (radial
left)
4x M75x1.5 846 751 369 371 x 370
1XB7-712 (radial
right)
4x M75x1.5 828 777 369 371 x 370
