Siemens SIMOTICS T-1FW3 User Manual

Installation drawings/Dimension drawings
9.2 Dimension drawings
1FW3 complete torque motors
322 Configuration Manual, 08/2020, A5E46027705B AA
Table 9- 7 Motor table
version
l
c
z*
weight
[mm]
[mm]
[mm]
[kg]
1FW3150
253.5
228.0
38 / 43
102
1FW3152
283.0
257.5
38 / 43
121
1FW3154
338.0
312.5
38 / 43
143
1FW3155
386.5
361.0
38 / 43
164
1FW3156
440.5
415.0
38 / 43
187
z* (z=38 for DQI / z=43 for angle socket); you can find additional dimensions in diagram "Encoder connection".
Table 9- 8 Table terminal box
version
thread
h
g
a x b
[mm]
[mm]
[mm]
gk 230
2x M32x1.5
393
140.5
122x117
gk 420
2x M40x1.5
409
158
162x162
gk 630
2x M50x1.5
427
206.5
210x210
