Siemens SIMOTICS T-1FW3 User Manual

Installation drawings/Dimension drawings
9.2 Dimension drawings
1FW3 complete torque motors
Configuration Manual, 08/2020, A5E46027705B AA
327
Table 9- 11 Motor table
version
l
c
d
f
z*
weight
[mm]
[mm]
[mm]
[mm]
[mm]
[kg]
1FW3281
553
463.5
258.0
393.0
36 / 41
750
1FW3283
637.5
548
342.5
477.5
36 / 41
880
1FW3285
763.5
674
468.5
603.5
36 / 41
1070
1FW3287
932
842.5
637.0
772.0
36 / 41
1300
z* (z=36 for DQI / z=41 for angle socket); you can find additional dimensions in the diagram "encoder connection".
Table 9- 12 Table terminal box
version (cable outlet
direction)
thread
h
W
g
a x b
[mm]
[mm]
[mm]
[mm]
1XB7-700
3x M75x1.5
742
665
377
306 x 306
1XB7-712 (axial
DE)
4x M75x1.5 836 744 368 371 x 370
1XB7-712 (axial
NDE)
836 744 399
1XB7-712 (radial
left)
846 731 383
1XB7-712 (radial
right)
828 764 383
