5.1 Terminal Module TM15
5.1.1 Description
The Terminal Module TM15 is a terminal expansion for snapping on to an EN 60715 DIN rail.
The TM15 can be used to increase the number of available digital inputs/outputs within a drive
system.
Table 5-1 Interface overview of the TM15
Type Quantity
DRIVE-CLiQ interfaces 2
Bidirectional digital inputs/outputs 24
(isolation in 3 groups each with 8 DI/DO)
Supplementary component descriptions
